Model: LG16M12M—LG40M32M Series
Refrigerants: R717 (Ammonia), R507, etc.
Design Conditions: +40°C condensing / -40°C evaporating temperature
Nominal Cooling Capacity:
117 kW – 1450 kW (R717)
157 kW – 2142 kW (R507)
Designed for low-temperature applications with evaporating temperatures below -25°C; significantly more efficient than single-stage compressor units with economizers
Various configuration options available based on refrigerant and operating conditions:
For R717, the pressure ratio between high and low stage ranges from 3 to 4
For R507A, the pressure ratio ranges from 2 to 3
Both high-stage and low-stage compressors are equipped with capacity regulation systems, ensuring high efficiency and economical operation under all low-temperature conditions
Staged startup for high- and low-stage compressors to minimize inrush current; low-stage compressor utilizes differential pressure oil supply
High-stage compressor can operate independently for rapid cooling with high efficiency
Compatible with multiple refrigerants, including R717, R507A, and R404A
Various configurations available to meet customized requirements
Standard control mode: automatic
This series is widely used in applications requiring artificial low-temperature environments, including:Food freezing and cold storage、Chemical process cooling、Gas compression and liquefaction、Aggregate cooling in construction、Scientific temperature control、Permafrost drilling、Sports venues refrigeration、Mine heat hazard mitigation.
| Item | Unit | LG16M12M | LG20M12M | LG20L16S | LG20T16M | ||
| Refrigerant | Type | R717 | |||||
|
Compressor |
Low Pressure Stage |
Model | LG16M | LG20M | LG20L | LG20T | |
| Theoretical Displacement | m³h | 598 | 1120 | 1486 | 1672 | ||
| High Pressure
Level |
Model | LG12M | LG12M | LG16S | LG16M | ||
| Theoretical Displacement | m³/h | 285 | 285 | 385 | 598 | ||
| Nominal Conditions | ℃ | +40/-40 | |||||
| Nominal Refrigerating Capacity | kW | 117 | 207 | 278 | 329 | ||
|
Rated Power of Main Motor |
Low Pressure Stage | kW | 55 | 110 | 132 | 160 | |
| High Pressure Stage | kW | 65 | 65 | 90 | 132 | ||
|
Electrical System |
Low Pressure Stage | 3N 50HZ 380V | |||||
| High Pressure Stage | 3N 50HZ 380V | ||||||
| Charging Volume of Refrigeration Oil | L | ~240 | ~360 | ~360 | ~500 | ||
| Diameter of Intake Pipe | mm | DN125 | DN150 | DN200 | DN200 | ||
| Diameter of Outtake Pipe | mm | DN65 | DN65 | DN80 | DN80 | ||
| Inlet and Outlet Pipe Diameter of Economizer | mm | DN50 | DN65 | DN65 | DN65 | ||
| Diameter of Safety Valve | mm | DN25 | DN25 | DN50 | DN50 | ||
|
Liquid/Oil Cooler |
Type | Shell and Tube | |||||
| Liquid Inlet Pipe Diameter | mm | DN32 | DN40 | DN40 | DN40 | ||
| Discharge Pipe Diameter | mm | DN50 | DN65 | DN65 | DN65 | ||
|
Oil Pump |
Type | ZHB80P6 | ZHB125P4 | ||||
| Motor Power | kW | 1.5 | 2.2 | ||||
| Dimensions (L*W*H) | mm | 5400x1640x23405400x1640x2460 | 6040x1940x2780 | 6260x1940x2830 | |||
| Net Weight of Unit | kg | ~3300 | ~4650 | ~6300 | ~7700 | ||
Note:
1.The main motorof the unit is confgured according to the nominal working condition.Under this configuration,the unit can be putinto operation at full
load under the evaporation temperature of-40℃or below.
2.Due to the difference in the working conditions of the unit,the powerofthe main motor may be ifferent,and the outine dimensions will ls vary with
the main motor,which are notlisted one by one in the table.
3.This table shows a long structure,if other forms are needed,it can be customized.
