| Project | |
| Inlet pressure MPa(G) | 0~0.5 |
| Outlet pressure MPa(G) | 0.2~4.5 |
| Inlet temperature ℃ | 5~40 |
| Outlet temperature ℃ | <50(1) |
| Flow regulation range % | 15~100 |
| Flow regulation mode of compressor | Slide valve (2) |
Table of technical parameters
|
Model |
unit |
SN12M-22 |
SN16S-30 |
SN16M-45 |
SN20S-65 |
SN20M-90 |
SN20L-110 |
SN20T-132 |
SN25M-160 |
SN25L-200 |
| Rated daily processing
capacity |
104Nm’/d |
0.5 |
0.7 |
1.5 |
2.0 |
2.5 |
3.0 |
3.5 |
4.5 |
6.0 |
| Inlet pressure |
MPa(G) |
-0.05-0.1 |
||||||||
| Inlet temperature | ℃ | 20 | ||||||||
| Outlet pressure | MPa(G) | 0.25~0.3 | ||||||||
| Motor power | kW | 22 | 30 | 45 | 65 | 90 | 110 | 132 | 160 | 200 |
| Mator explosion proof | Ex dIIBT4（Optional） | |||||||||
| Model | unit | SN16S
-55 |
SN16M
-75 |
SN20S
-110 |
SN20M
-160 |
SN20L
-185 |
SN20T
-220 |
SN25M
-280 |
SN25L
-355 |
SN32S
-450 |
SN32M
-560 |
SN32T
-800 |
SN40M
-1000 |
| Rated dally processing capacity |
104N㎡’/d |
15 |
2.5 |
3.5 |
4.5 |
6.5 |
7.0 |
9.5 |
12 |
15 |
18 |
25 |
30 |
| Inlet pressure |
MPa(G) |
0.1~0.3 |
|||||||||||
| Inlet temperature | ℃ | 20 | |||||||||||
| Outlet pressure | MPa(G) | 0.5~0.7 | |||||||||||
| Motor power | kw | 55 | 75 | 110 | 160 | 185 | 220 | 280 | 355 | 450 | 560 | 800 | 1000 |
| Motor explosion proof | Ex dIIBT4（Optional） | ||||||||||||
| Model | unit | SN16S
-75 |
SN16M
-110 |
SN20S
-160 |
SN20M
-185 |
SN20L
-250 |
SN20T
-280 |
SN25M
-400 |
SN25L
-450 |
SN32S
-560 |
SN32M
-710 |
SN32T
-1000 |
SN40M
-1400 |
| Rated dally
processing capacity |
104N㎡’/d |
1.5 |
2.5 |
3.5 |
4.5 |
6.5 |
7.0 |
9.5 |
12 |
15 |
18 |
25 |
30 |
| Inlet pressure | MPa(G) | 0.1-0.3 | |||||||||||
| Inlet temperature | ℃ | 20 | |||||||||||
| Outlet pressure | MPa(G) | 1.0~1.2 | |||||||||||
| Motor power | kw | 75 | 110 | 160 | 185 | 250 | 280 | 400 | 450 | 560 | 710 | 1000 | 1400 |
| Motor explosion
proof |
Ex dIIBT4（Optional） |
||||||||||||
